LIB TECH
ORCA II TECHNO SPLIT SPLITBOARD
products.product.pickup_availability.unavailable
The Lib Tech Orca II Techno Split carries the Orca's directional float and compact turning platform into a touring-focused splitboard. Its lightweight wood core is reinforced with carbon and magnesium, with Spin Slim tips helping reduce mass at the ends. Karakoram UltraClip 2.0 connectors and Tip Locks join the board for the descent. A sintered base and directional C2x profile complete the setup; Lib Tech recommends sizing about 3 cm shorter.
Features and Construction
|
Feature |
Details |
|
Recommended for |
Splitboard touring and freeride |
|
Shape / profile |
Directional splitboard; Orca directional C2x |
|
Edges |
Magne-Traction serrated edges |
|
Core |
15% aspen / 85% lightweight paulownia |
|
Fiberglass / reinforcement |
UNIDIRECTIONAL CARBON / 30º CARBON MEGA X / MAGNESIUM TECHNO FIBER BANDS |
|
Topsheet |
Eco sublimated poly top |
|
Base |
Sintered knife cut base |
|
Tips / tails |
Lightweight spin slim |
|
Split connectors |
Karakoram UltraClip 2.0 and Tip Locks |
Lib Tech Orca II Techno Split
Profile and Size Guide
Measurements below correspond to the sizes listed on the invoice. Flex is rated out of 10, with 10 the firmest.
|
Size (cm) |
156 |
159 |
|
Contact length (cm) |
113 |
115 |
|
Sidecut (m) |
8 |
8 |
|
Nose / tail width (cm) |
30.8 / 30.1 |
31.1 / 30.2 |
|
Waist width (cm) |
26.5 |
26.7 |
|
Surface area (sq in) |
673 |
686 |
|
Stance min-max / set back (in) |
17"-24" / 1.5" |
17"-24" / 1.5" |
|
Stance min-max / set back (cm) |
43.2 - 60.9 / 3.8 cm |
43.2 - 60.9 / 3.8 cm |
|
Flex 10 = firm |
8 |
8 |
|
Weight range (lbs / kg) |
140+ / 70+ |
150+ / 75+ |
